Specification Parameters
Supports 13 to 20 series lithium battery management systems, providing overvoltage, undervoltage, overcurrent, high temperature, low temperature, and short circuit protection and recovery for the battery pack and individual cells, with adjustable protection and recovery parameters via software.
Supports a maximum current of up to 45A.
Real-time monitoring of the voltage of each cell string.
Features 2 channels for battery temperature monitoring and 1 channel for MOS temperature monitoring.
Supports RS485 communication functionality.
Supports pre-charge function for discharging.
Individual cell balancing function.
GPS functionality reserved.
Equipped with an RTC clock function.
Widely applicable to two-wheeled, three-wheeled electric vehicles, motorcycles, low-speed vehicles, and forklifts.
